 YDK-250-6 1 |
 |
|
YDK-250-6 1 |
|
| Brand Name: | Powerstar | Model Number: | YDK-250-4 | Type: | Asynchronous Motor | working condiction | continuious |
| Frequency: | 50/60hz | Output Power: | 1/3HP | Protect Feature: | Totally Enclosed | Pole | 4 |
| Phase: | Single-phase | Certification: | ROHS,UL | AC Voltage: | 115V/208-230V | current | 3.1A |
| Place of Origin: | Guangdong China (Mainland) | Efficiency: | IE 3 | Approval: | UL,ROHS | shape | tubular |
| Speed: | 1440rpm | Bearing: | Ball bearing | Protect feature: | semi-enclosed | color | black |
| open or enclosed: | semi-enclosed | rotation | reversible | insulation class | H | shaft | 14mm |
| Multi Horse Condenser Fan Motor | ||||||||||
| Part No. | Model | Power(HP) | Voltage(V) | Frequency(Hz) | Speed(rpm) | APMS | ROT | Pole | Bearing | shaft(mm) |
| 1 | YDK-180-4 | 1/4 | 208-230 | 50/60 | 1440 | 2.8 | REV. | 4 | ball | 14 |
| 2 | YDK-250-4 | 1/3 | 208-230 | 50/60 | 1440 | 3.1 | REV. | 4 | ball | 14 |
| 3 | YDK-370-4 | 1/2 | 208-230 | 50/60 | 1440 | 4.3 | REV. | 4 | ball | 16 |
| 4 | YDK-550-4 | 3/4 | 208-230 | 50/60 | 1440 | 4.8 | REV. | 4 | ball | 16 |
| 5 | YDK-750-4 | 1 | 208-230 | 50/60 | 1430/1720 | 2.8 | REV. | 4 | ball | 20 |
| 6 | YDK-1100-4 | 1 1/2 | 208-230 | 50/60 | 1430/1720 | 5.7/4.9 | REV. | 4 | ball | 20 |
| 7 | YDK-1500-4 | 2 | 208-230 | 50/60 | 1430/1720 | 8.2/7.7 | REV. | 4 | ball | 28 |
| 8 | YDK-2200-4 | 3 | 208-230 | 50/60 | 1430/1720 | 9.3/8.8 | REV. | 4 | ball | 28 |
