| Brand Name: | Powerstar | Model Number: | YDZ-180-4 | Type: | Asynchronous Motor | ||
| Frequency: | 50/60hz | Output Power: | 1/4 HP | Pole | 4 | ||
| Phase: | Single-phase | Certification: | ROHS,UL | AC Voltage: | 110/220V | insulation class | H |
| Place of Origin: | Guangdong China (Mainland) | Efficiency: | IE 3 | Approval: | CCC, UL,ROHS | Output Shaft DIA | 15 mm |
| Speed: | 1400/1680 rpm | Bearing: | Ball bearing | Protect feature: | Totally Enclosed | shape | tubular |
| open or enclosed: | open or enclosed | rotation | reversible | insulation class | H | ratios | 30:1/ 50:1/ 60:1/ 80:1 |
| Geared Motors | |||||||||||
| Model | Power(HP) | Voltage(V) | Frequency(Hz) | Pole | Speed(RPM) | Ratios | Output Shaft（mm） | Bearing | DIA（mm） | Protect Feature | Insulation Class |
| YDZ-250-4 | 1/3 | 110/220 | 50/60 | 4 | 1400/1680 | 30:1/ 50:1/ 60:1/ 80:1 | 15 | ball | 94 | totally-enclosed | H |
| YDZ-180-4 | 1/4 | 110/220 | 50/60 | 4 | 1400/1680 | 30:1/ 50:1/ 60:1/ 80:1 | 15 | ball | 94 | totally-enclosed | H |
| YDZ-150-4 | 1/5 | 110/220 | 50/60 | 4 | 1400/1680 | 30:1/ 50:1/ 60:1/ 80:1 | 15 | ball | 94 | totally-enclosed | H |
